1. Glass servo correction, one-key switching of different modules.
2. Glue pump, pressure station, metering pump, etc. ensure glue injection accuracy.
3. Visual inspection of the gap between EVA film and glass.
Function
1. Glass servo correction, one-key switching of different modules.
2. Glue pump, pressure station, metering pump, etc. ensure glue injection accuracy.
3. Visual inspection of the gap between EVA film and glass.
Technical Performance
1. Butyl adhesive application width: 5-12mm, accuracy ±0.5mm.
2. Butyl adhesive application thickness: straight edge 0.8-2mm, overlap 1-4mm, accuracy ±0.1mm(overlap ±0.5mm).
3. Butyl adhesive offset accuracy: ≤0.5mm.
4. Cycle time: ≤30S.
Technical Parameters
| Item | Parameter |
| Panel size | L:1650-2500(mm);W:990-1400(mm) |
| Voltage | AC380V±5%, 50HZ |
| Air pressure | 0.6-0.8 (Mpa) |
| Air source flow (equipment) | 500L/min |
| Air source flow (glue supply pump) | 2*850L/min |
| Overall size (L*H*W) | 3950*2500*4000(mm) |
| weight | about 3500kg |
