1. Automatically frame barcode labeling and backplate nameplate.
2. Glass servo correction, one-click switching of different types of panels.
Function
1. Automatically frame barcode labeling and backplate nameplate.
2. Glass servo correction, one-click switching of different types of panels.
Technical Performance
1. The fastest cycle tims is 13s.
2. Activity rate: ≥99.5%.
Technical Parameters
| Item | Parameter |
| Panel size | L:1640-2550(mm);W:990-1450(mm) |
| Voltage | AC380V±5%, 3P+1N+1PE, 32A, 50/60Hz |
| Power | 8kw |
| Air pressure | 0.5-0.8(Mpa) |
| Noise | <80dB |
| Overall size (L*H*W) | 4330*2250*2200(mm) |
| weight | about 2800kg |
| Cycle time | 13s |
| Labeling accuracy | ±1mm |
