1. The moving unit is driven by a servo motor, with fast speed, high accuracy, stable and reliable.
2. Optional hot air gun to help pick the fuse.
3. Multiple vision verification options available to ensure lead molding dimensions.
4. The equipment can be slightly modified to tear high-temperature tape.
5. Tear off high temperature cloth or tape has a collection box to collect.
Function
1. The moving unit is driven by a servo motor, with fast speed, high accuracy, stable and reliable.
2. Optional hot air gun to help pick the fuse.
3. Multiple vision verification options available to ensure lead molding dimensions.
4. The equipment can be slightly modified to tear high-temperature tape.
5. Tear off high temperature cloth or tape has a collection box to collect.
Technical Performance
1. Regular, half-cell, MBB breakage rate: ≤0.04%
2. Compatible cell type: 60 half-cell 172 half-cell/MBB half-cell.
3. Utilization rate: >99%.
Technical Parameters
| Item | Parameter |
| Panel size | L:1650-2550(mm);W:990-1450(mm) |
| Voltage | AC380V±5%, 3P+1N+1PE, 32A, 50/60HZ |
| Power | ≤8kw |
| Air pressure | 0.5-0.8(Mpa) |
| Noise | <70dB |
| Overall size (L*H*W) | 3450*1900*1850(mm) |
| weight | about 2500kg |
| Cyele time | 13s |
| Air consumption | 450L/min |
