1. Using upper and lower knives to finely cut the adhesive film, the speed is fast and the accuracy can reach + 0.5mm
2. Automatic correction of adhesive film pulling material, high laying accuracy.
3. Automatic roll changing has high efficiency, with a roll changing time of less than 50 seconds per time and no downtime for material changing.
Function
1. Accurate four sided cutting and laying of adhesive film.
2. Automatic hot melt roll change, material change without stopping.
3. The equipment has high compatibility and high cutting efficiency.
Technical Performance
1. Using upper and lower knives to finely cut the adhesive film, the speed is fast and the accuracy can reach + 0.5mm
2. Automatic correction of adhesive film pulling material, high laying accuracy.
3. Automatic roll changing has high efficiency, with a roll changing time of less than 50 seconds per time and no downtime for material changing.
Technical Parameters
| Item | Parameter |
| Panel size | L:1650-2650(mm);W:990-1450(mm) |
| Voltage | AC380V±5%, 3P+1N+1PE, 25A, 50/60HZ |
| Power | 15kw |
| Air pressure | 0.5-0.8 (Mpa) |
| Noise | <70dB |
| Overall size (L*H*W) | 7300*5300*3400(mm) |
| weight | about 8000kg |
| Cutting accuracy | ±0.5mm |
| Cyele time | 14s |
