1. Efficient and fast cutting and feeding of small materials, pasting internal barcodes of busbars.
2. Glass servo straightening, one click switching between different types of panels.
3. The cutting size of small materials is precisely controlled by servo motors.
4. Using visual guidance for label selection and labeling.
Function
1. Efficient and fast cutting and feeding of small materials, pasting internal barcodes of busbars.
2. Glass servo straightening, one click switching between different types of panels.
3. The cutting size of small materials is precisely controlled by servo motors.
4. Using visual guidance for label selection and labeling.
Technical Performance
1. Cutting small materials, feeding small materials, and printing barcodes are synchronized, with a fastest cycle time of 13 seconds.
2. There is a visual guidance system for feeding small materials.
3. Using visual guidance for label selection and labeling.
4. Utilization rate: ≥99%.
Technical Parameters
| Item | Parameter |
| Panel size | L:1640-2550(mm);W:990-1450(mm) |
| Voltage | AC380V±5%, 3P+1N+1PE, 32A, 50/60HZ |
| Power | 8kw |
| Air pressure | 0.5-0.8 (Mpa) |
| Noise | <80dB |
| Overall size (L*H*W) | 4000*2200*2200(mm) |
| weight | about 2800kg |
| Labeling accuracy | ±1mm |
| Cyele time | 13s |
| Small material cutting accuracy | ±0.5mm |
