1. Adopting constant tension synchronous feeding and automatic correction function.
2. Automatic hot melt roll change, material change without stopping.
3. Glass servo straightening, one click switching between different types of components.
Function
1. Adopting constant tension synchronous feeding and automatic correction function.
2. Automatic hot melt roll change, material change without stopping.
3. Glass servo straightening, one click switching between different types of components.
Technical Performance
1. Cancel the pre discharge action to improve the laying accuracy, with a laying accuracy of ±1.5mm.
2.Automatic roll changing has high efficiency, with a roll changing time of less than 50 seconds per time and no downtime for material changing.
Technical Parameters
| Item | Parameter |
| Panel size | L:1650-2650(mm);W:990-1450(mm) |
| Voltage | AC380V±5%, 3P+1N+1PE, 25A, 50/60HZ |
| Power | 8kw |
| Air pressure | 0.5-0.8 (Mpa) |
| Noise | <70dB |
| Overall size (L*H*W) | 6570*1800*2050(mm) |
| weight | about 3300kg |
| Cutting accuracy | ±1.5mm |
| Cyele time | 15s |
