1. All four heads are controlled by servo motors, with high precision and good stability.
2. Servo correction, one click switching between models.
3. Take photos with the discharge camera to check if the tape has been torn off.
Function
1. All four heads are controlled by servo motors, with high precision and good stability.
2. Servo correction, one click switching between models.
3. Take photos with the discharge camera to check if the tape has been torn off.
Technical Performance
1. Fully automatic control of the equipment, without the need for personnel intervention during operation.
2. Equipped with a waste tape collection box.
3. High precision lifting platform.
Technical Parameters
| Item | Parameter |
| Panel size | L:1640-2550(mm);W:990-1450(mm) |
| Voltage | AC380V±5%, 3P+1N+1PE, 32A, 50/60HZ |
| Power | 8kw |
| Air pressure | 0.5-0.8 (Mpa) |
| Noise | <75dB |
| Overall size (L*H*W) | 3870*2860*1800(mm) |
| weight | about 2500kg |
| Cyele time | 13s |
| Compatible with tape width | 20~40mm |
