Select the blade type according to the film of different modules. The trimming surface is smooth after trimming, and there is no adhesion to the modules.
Function
1. Integrated edge trimming and corner trimming functions.
2. Select the blade type according to the film of different modules. The trimming surface is smooth after trimming, and there is no adhesion to the modules.
3. All trimming blade cylinder pressure can be adjusted individually.
Technical Performance
1. 8 servo blade modules, cycle time 13s.
2. Cylinder positioning, accuracy ±1mm.
Technical Parameters
| Item | Parameter |
| Panel size | L:1650-2550(mm);W:990-1450(mm) |
| Voltage | AC380V±5%, 3P+1N+1PE, 20A, 50/60HZ |
| Power | 4kw |
| Air pressure | 0.5-0.7(Mpa) |
| Noise | <70dB |
| Overall size (L*H*W) | 3640*2400*1550(mm) |
| weight | about 2200kg |
| Cyele time | 13s |
