1. Glass servo correction, one-key switching of different version panels.
2. Guide positioning through reliable visual system detection
3. The motion unit is driven by a servo motor, which is fast, accurate, stable and reliable.
4. The hot spot adopts electromagnetic welding and air cooling.
Function
1. Glass servo correction, one-key switching of different version panels.
2. Guide positioning through reliable visual system detection
3. The motion unit is driven by a servo motor, which is fast, accurate, stable and reliable.
4. The hot spot adopts electromagnetic welding and air cooling.
Technical Performance
1. Conventional, half-cell, MBB fragmentation rate: <0.04%
2. Compatible cell specifications: 60 half-cell, 172 half-cell/MBB half-cell
3. Spotting diameter: ≤15mm
4. Spotting method: electromagnetic welding
5. Visual system: guided positioning.
6. Visual accuracy: ≤±0.1mm.
Technical Parameters
| Item | Parameter |
| Panel size | L:1650-2520(mm);W:990-1450(mm) |
| Voltage | AC380V±5%, 3P+1N+1PE, 32A, 50/60HZ |
| Power | ≤8kw |
| Air pressure | 0.5-0.8 (Mpa) |
| Noise | <70dB |
| Overall size (L*H*W) | 3370*1920*1800(mm) |
| weight | about 2000kg |
| Cyele time | ≤13s |
| Gas consumption | 300L/min |
